1.5SMCJ100CA (Diotec) is a 1500 W bidirectional SMD transient voltage suppressor (TVS) diode in an SMC package (DO-214AB), for a 100 V working voltage.

• 1500 W peak pulse power (10/1000 µs waveform) · very fast response time
• 100 V reverse working voltage (VWM) · 111 to 123 V breakdown voltage (VBR)
• 162 V clamping voltage (VC) at 9.3 A peak pulse current · 150 °C maximum junction temperature
• Uni- and bidirectional versions (CA = bidirectional) · uses: overvoltage and ESD protection, free-wheeling diodes

Minimum order: 50

Data per Diotec 1.5SMCJ5.0...1.5SMCJ170CA datasheet.
